1U Rackmount Workstation


RM-170129-WS

CPU : Quad Core -2.16GHz (7.5W)
RAM : Up to 8G DDR3 1333MHz
HD Bay : 4 slim hot-swap HD-SSD bays
USB : 2 x USB3.0 + 6 x USB2.0
LAN : 2 x Gb LAN
Video : VGA, HDMI
COM : 3 x RS232/422/485
PS2 : 2x PS2,
Audio : 2 x Audio
DC Power : DC12~110V
AC Power : AC90~264V
Option : Redundant Power Supply


1U Rackmount Workstation


RM-170176-WS



CPU : i5-33337U ~2.7GHz (17W)
RAM : Up to 16G DDR3 1600MHz
HD Bay : 4 slim HD hot-swap bay
USB : 2 x USB3.0 + 6 x USB2.0
LAN : 2 x Gb LAN
Video : 1 x DVI, 2 x HDMI
COM : 4 x COM (Max : 6)
PS2 : 2 x PS2
Power Consumption : 30 Watts
Power Input : AC90~264V

Option : Redundant Power Supply

optional 48 or 110V dc power


1U Rackmount Server


RM-170188-i5-SV



CPU : i5-4300U ~2.9GHz (15W)
RAM : Up to 16G DDR3 1600MHz
HD Bay : 4 slim hot-swap HD bay
RAID : Support 0, 1, 5, 10
USB : 4 x USB3.0 + 4 x USB2.0
LAN : 2 x Giga bit LAN
Video : 1 x HDMI, 1 x DP
COM : 4 x COM (Option : 6)
Audio : 2 x Audio
Power Consumption : 30W
DC Power : DC12~110V
AC Power : AC90~264V
Option : Redundant Power Supply


1U Rackmount Server


RM-170188-i7-SV



CPU : i5-4650U ~2.9GHz (15W)
RAM : Up to 16G DDR3 1600MHz
HD Bay : 4 slim hot-swap HD bay
RAID : Support 0, 1, 5, 10
USB : 4 x USB3.0 + 4 x USB2.0
LAN : 2 x Giga bit LAN
Video : 1 x HDMI, 1 x DP
COM : 4 x COM (Option : 6)
Audio : 2 x Audio
Power Consumption : 30W
DC Power : DC12~110V
AC Power : AC90~264V
Option : Redundant Power Supply


1U Rackmount Workstation


RM-170177-i5-WS



CPU : i5-3230M ~3.2GHz (35W)
RAM : Up to 16G DDR3 1600MHz
USB : 2 Front + 6 Rear
RAID : Support 0, 1, 5, 10
HDD : 4 x slim HD-SSD hot-swap bay
LAN : 2 x Giga bit LAN
Video : VGA, HDMI, DP
COM : 4 x COM (Max : 6)
PS2 : 1x PS2
Audio : 3 x Audio
Power Consumption : 50W
Power Input : AC90~264V
Option : Redundant Power Supply


1U Rackmount Server


RM-170177-i7-SV



CPU : i7-3520M ~3.6GHz (35W)
RAM : Up to 16G DDR3 1600MHz
USB : 2 Front + 6 Rear
RAID : Support 0, 1, 5, 10
HDD : 4 x slim HD-SSD hot-swap bay
LAN : 2 x Giga bit LAN
Video : VGA, HDMI, DP
COM : 4 x COM (Max : 6)
PS2 : 1x PS2
Audio : 3 x Audio
Power Consumption : 50W
Power Input : AC90~264V
Option : Redundant Power Supply


1U Rackmount Server


RM-1701612-SX-SV



Xeon E5-2620 V3 ~3.2GHz (85W)
6 Core, 15MB cache
RAM : 32G DDR4 2133 (Max : 256GB)
USB : 2 Front + 6 Rear
RAID : Support 0, 1, 5, 10
HD Bay : 4 x slim hot-swap SSD bay
LAN : 2 x Gb LAN
IPMI LAN : 1 x IPMI LAN
Video : 1 x VGA
COM : 1 x RS232
Power Consumption : 100W only
Power Input : AC90~264V
Option : Redundant Power Supply


1U Rackmount Server

RM-1701612-DX-SV



Dual Xeon E5-2620 V3 ~3.2GHz
6 Core, 15M cache, 85W, 73C
RAM : 32G DDR4 2133 (Max : 1TB)
USB : 2 Front + 6 Rear
RAID : Support 0, 1, 5, 10
HD Bay : 4 hot-swap HD/SSD bay
LAN : 4 x Gb LAN
IPMI LAN : 1 x IPMI LAN
Video : 1 x VGA
COM : 1 x RS232
Slot : optional 3 x PCIe x16
Power Consumption : 100W
Power Input : AC90~264V
Option : Redundant Power Supply


2U Rackmount Workstation


RM-170229-WS

CPU : Quad Core -2.16GHz (7.5W)
RAM : Up to 8G DDR3 1333MHz
HD Bay : 4 slim hot-swap HD-SSD bays
USB : 2 x USB3.0 + 6 x USB2.0
LAN : 2 x Gb LAN
Video : VGA, HDMI
COM : 3 x RS232/422/485
PS2 : 2x PS2,
Audio : 2 x Audio
DC Power : DC9~19V
AC Power : AC90~264V
Option : Redundant Power Supply


2U Rackmount Workstation


RM-170276-WS



CPU : i5-33337U ~2.7GHz (17W)
RAM : Up to 16G DDR3 1600MHz
HD Bay : 4 slim HD hot-swap bay
USB : 2 x USB3.0 + 6 x USB2.0
LAN : 2 x Gb LAN
Video : 1 x DVI, 2 x HDMI
COM : 4 x COM (Max : 6)
PS2 : 2 x PS2
Power Consumption : 30 Watts
Power Input : AC90~264V

Option : Redundant Power Supply

optional 48 or 110V dc power


2U Rackmount Server


RM-170288-i5-SV



CPU : i5-4300U ~2.9GHz (15W)
RAM : Up to 16G DDR3 1600MHz
HD Bay : 4 slim hot-swap HD bay
RAID : Support 0, 1, 5, 10
USB : 4 x USB3.0 + 4 x USB2.0
LAN : 2 x Giga bit LAN
Video : 1 x HDMI, 1 x DP
COM : 4 x COM (Option : 6)
Audio : 2 x Audio
Power Consumption : 30W
DC Power : DC9~19V
AC Power : AC90~264V
Option : Redundant Power Supply


2U Rackmount Server


RM-170288-i7-SV



CPU : i5-4650U ~2.9GHz (15W)
RAM : Up to 16G DDR3 1600MHz
HD Bay : 4 slim hot-swap HD bay
RAID : Support 0, 1, 5, 10
USB : 4 x USB3.0 + 4 x USB2.0
LAN : 2 x Giga bit LAN
Video : 1 x HDMI, 1 x DP
COM : 4 x COM (Option : 6)
Audio : 2 x Audio
Power Consumption : 30W
DC Power : DC9~19V
AC Power : AC90~264V
Option : Redundant Power Supply


2U Rackmount Workstation


RM-170277-i5-WS



CPU : i5-3230M ~3.2GHz (35W)
RAM : Up to 16G DDR3 1600MHz
USB : 2 Front + 6 Rear
RAID : Support 0, 1, 5, 10
HDD : 4 x slim HD-SSD hot-swap bay
LAN : 2 x Giga bit LAN
Video : VGA, HDMI, DP
COM : 4 x COM (Max : 6)
PS2 : 1x PS2
Audio : 3 x Audio
Power Consumption : 50W
Power Input : AC90~264V
Option : Redundant Power Supply


2U Rackmount Server


RM-170277-i7-SV



CPU : i7-3520M ~3.6GHz (35W)
RAM : Up to 16G DDR3 1600MHz
USB : 2 Front + 6 Rear
RAID : Support 0, 1, 5, 10
HDD : 4 x slim HD-SSD hot-swap bay
LAN : 2 x Giga bit LAN
Video : VGA, HDMI, DP
COM : 4 x COM (Max : 6)
PS2 : 1x PS2
Audio : 3 x Audio
Power Consumption : 50W
Power Input : AC90~264V
Option : Redundant Power Supply


2U Rackmount Server


RM-1702612-SX-SV



Xeon E5-2620 V3 ~3.2GHz (85W)
6 Core, 15MB cache
RAM : 32G DDR4 2133 (Max : 256GB)
USB : 2 Front + 6 Rear
RAID : Support 0, 1, 5, 10
HD Bay : 4 x slim hot-swap HD bay
LAN : 2 x Gb LAN
IPMI LAN : 1 x IPMI LAN
Video : 1 x VGA
COM : 1 x RS232
Power Consumption : 100W only
Power Input : AC90~264V
Option : Redundant Power Supply


2U Rackmount Server

RM-1702612-DX-SV



Dual Xeon E5-2620 V3 ~3.2GHz
6 Core, 15M cache, 85W, 73C
RAM : 32G DDR4 2133 (Max : 1TB)
USB : 2 Front + 6 Rear
RAID : Support 0, 1, 5, 10
HD Bay : 4 hot-swap HD/SSD bay
LAN : 4 x Gb LAN
IPMI LAN : 1 x IPMI LAN
Video : 1 x VGA
COM : 1 x RS232
Slot : optional 3 x PCIe x16
Power Consumption : 100W
Power Input : AC90~264V
Option : Redundant Power Supply


4U Rackmount Workstation


RM-170429-WS

CPU : Quad Core -2.16GHz (7.5W)
RAM : Up to 8G DDR3 1333MHz
HD Bay : 4 slim hot-swap HD-SSD bays
USB : 2 x USB3.0 + 6 x USB2.0
LAN : 2 x Gb LAN
Video : VGA, HDMI
COM : 3 x RS232/422/485
PS2 : 2x PS2,
Audio : 2 x Audio
DC Power : DC9~19V
AC Power : AC90~264V
Option : Redundant Power Supply
Option : 10" LCD Display


4U Rackmount Workstation


RM-170476-WS



CPU : i5-33337U ~2.7GHz (17W)
RAM : Up to 16G DDR3 1600MHz
HD Bay : 4 slim HD hot-swap bay
USB : 2 x USB3.0 + 6 x USB2.0
LAN : 2 x Gb LAN
Video : 1 x DVI, 2 x HDMI
COM : 4 x COM (Max : 6)
PS2 : 2 x PS2
Power Consumption : 30 Watts
Power Input : AC90~264V

Option : Redundant Power Supply
Option : 10" LCD Display

optional 48 or 110V dc power


4U Rackmount Server


RM-170488-i5-SV



CPU : i5-4300U ~2.9GHz (15W)
RAM : Up to 16G DDR3 1600MHz
HD Bay : 4 slim hot-swap HD bay
RAID : Support 0, 1, 5, 10
USB : 4 x USB3.0 + 4 x USB2.0
LAN : 2 x Giga bit LAN
Video : 1 x HDMI, 1 x DP
COM : 4 x COM (Option : 6)
Audio : 2 x Audio
Power Consumption : 30W
DC Power : DC9~19V
AC Power : AC90~264V
Option : Redundant Power Supply

Option : 10" LCD Display


4U Rackmount Server


RM-170488-i7-SV



CPU : i5-4650U ~2.9GHz (15W)
RAM : Up to 16G DDR3 1600MHz
HD Bay : 4 slim hot-swap HD bay
RAID : Support 0, 1, 5, 10
USB : 4 x USB3.0 + 4 x USB2.0
LAN : 2 x Giga bit LAN
Video : 1 x HDMI, 1 x DP
COM : 4 x COM (Option : 6)
Audio : 2 x Audio
Power Consumption : 30W
DC Power : DC9~19V
AC Power : AC90~264V
Option : Redundant Power Supply

Option : 10" LCD Display


4U Rackmount Workstation


RM-170477-i5-WS



CPU : i5-3230M ~3.2GHz (35W)
RAM : Up to 16G DDR3 1600MHz
USB : 2 Front + 6 Rear
RAID : Support 0, 1, 5, 10
HDD : 4 x slim HD-SSD hot-swap bay
LAN : 2 x Giga bit LAN
Video : VGA, HDMI, DP
COM : 4 x COM (Max : 6)
PS2 : 1x PS2
Audio : 3 x Audio
Power Consumption : 50W
Power Input : AC90~264V
Option : Redundant Power Supply

Option : 10" LCD Display


4U Rackmount Server


RM-170477-i7-SV



CPU : i7-3520M ~3.6GHz (35W)
RAM : Up to 16G DDR3 1600MHz
USB : 2 Front + 6 Rear
RAID : Support 0, 1, 5, 10
HDD : 4 x slim HD-SSD hot-swap bay
LAN : 2 x Giga bit LAN
Video : VGA, HDMI, DP
COM : 4 x COM (Max : 6)
PS2 : 1x PS2
Audio : 3 x Audio
Power Consumption : 50W
Power Input : AC90~264V
Option : Redundant Power Supply

Option : 10" LCD Display


4U Rackmount Server


RM-1704612-SX-SV



Xeon E5-2620 V3 ~3.2GHz (85W)
6 Core, 15MB cache
RAM : 32G DDR4 2133 (Max : 256GB)
USB : 2 Front + 6 Rear
RAID : Support 0, 1, 5, 10
HD Bay : 4 x slim hot-swap SSD bay
LAN : 2 x Gb LAN
IPMI LAN : 1 x IPMI LAN
Video : 1 x VGA
COM : 1 x RS232
Power Consumption : 100W only
Power Input : AC90~264V
Option : Redundant Power Supply

Option : 10" LCD Display


4U Rackmount Server

RM-1704612-DX-SV



Dual Xeon E5-2620 V3 ~3.2GHz
6 Core, 15M cache, 85W, 73C
RAM : 32G DDR4 2133 (Max : 1TB)
USB : 2 Front + 6 Rear
RAID : Support 0, 1, 5, 10
HD Bay : 4 hot-swap HD/SSD bay
LAN : 4 x Gb LAN
IPMI LAN : 1 x IPMI LAN
Video : 1 x VGA
COM : 1 x RS232
Slot : optional 3 x PCIe x16
Power Consumption : 100W
Power Input : AC90~264V
Option : Redundant Power Supply
Option : 10" LCD Display

Note : Above product specifications are subject to upgrade or change without prior notification. Photos may not show actual product photos.
  For pricing and detailed specifications or custom configurations, please contact us at sales@cepoint.net
